Product Description
Features:
1. 120W Max power handing
2. 35 mm inside/outside Copper Clad Aluminium voice coil
3. 120hz-8khz Frequency Response
4. Neodymium magnet allows a very light yet powerful motor assembly
5. Special coating on the cone, to help tp improve the sound quality.
| Specifications: | |
| Nominal diameter | 5 inch |
| Nominal impedance | 8 Ω |
| RMS Power rating | 60W |
| Max power handing | 120W |
| Sensitivity (1w/1m) | 96dB |
| Frequency range | 120hz-8KHz |
| Voice coil diameter | Φ35 mm |
Basket |
Die-Casting Aluminium |
| Cone and dust cap | Paper |
| Surround | Cloth |
| Voice coil wire | CCAW |
| Voice coil former | Glassfiber |
| Magnet | Neodymium |
| Net weight | 1.64KG |
| Thiele-Small Parameters | |
| Fs | 78.6 Hz |
| Re (D.C.) | 5.5 Ω |
| Qms | 3.62 |
| Qes | 0.38 |
| Qts | 0.35 |
| Vas | 3.6 L |
| Cms | 0.31 u M/N |
| Bl | 9.7 T |
