6.5 Inch Carbon Cone Coaxial Audio Speakers 650-044 200W RMS OEM Passive Speakers with 8 Ohm Impedance Line Array Speaker

Spu:
1600481423689
  • Overview
  • Recommended Products



Product Description



Features:

  • 6.5 inch Coaxial speaker with big horn
  • 200Wrms power handling, 400W max power
  • 45hz- 20kHz frequency response
  • Carbon cone for high quality usage
  • Single ferrite magnet assembly
  • Inside/Outside CCAW voice coil



Specification
Nominal diameter
160/6.5
mm/inch
Nominal impedance
8
ohm
Min impedance LF
7.2
ohm
Min impedance HF
6
ohm
Frequency response
45-20k
Hz
  RMS Power
200

Magnet material
   Ferrite
Specification LF
Sensitivity (1w/1m)
   91
dB
Nominal power handling
200
Watts
Continuous power handling
400
Watts
Voice coil diameter
50/2
mm/ inch
Winding material
CCAW

Cone material
Carbon

Surround material
Cloth

Specification HF
Sensitivity (1w/1m)
95
dB
Nominal power handling
   35
Watts
Continuous power handling
70
Watts
Voice coil diameter
34/1.4
mm/inch
Diaphragm
Titanium

T/S Parameter
Fs
100
Hz
Re
7.2

Qes
0.64
Qts
0.58
Qms
5.87
Vas
2.63
L
Rms
2.35
kg/s
Cms
0.11
mm/N
Mms
21.85
gr
BL
12.43
N/A
Mounting information
Overall diameter
175/6.9
mm/inch
Bolt Circle diameter
161/6.33
mm/inch
Baffle Cutout diameter
150/5.9
mm/inch
Total Depth
120/4.72
mm/inch
Shipping information
Net weight
3.6
KG
Shipping weight
4.2
KG
Shipping box
200x200x145
mm
